Huawei Wbbp D2
Huawei Computer Hardware Part Catalog 64 Are you looking for VP9610 NL FR, VPC500, VSPA AS21VSPA0, VXUA AS31VSUA0, W05MARU261-1 from Huawei? ASAP IT Technology, owned. Huawei Cmpt Wd22cmpt01 020mrn New Spot Inventory For Huawei Bbu3900 Bbu3910, Find Complete Details about Huawei Cmpt Wd22cmpt01 020mrn New Spot Inventory For Huawei Bbu3900 Bbu3910,Huawei Cmpt,Huawei Wd22cmpt01,Huawei.
- Released 2013, March
170g, 9.4mm thickness
Android 4.1
32GB storage, no card slot - N/A1,011,224 hits
- 5.0'1080x1920 pixels
- 13MP
- 2GB RAMHuawei K3V2
- 3000mAh
| Network | Technology | GSM / HSPA |
|---|---|---|
| 2G bands | GSM 850 / 900 / 1800 / 1900 | |
| 3G bands | HSDPA 850 / 900 / 2100 | |
| Speed | HSPA 42.2/5.76 Mbps |
| Launch | Announced | 2013, January. Released 2013, March |
|---|---|---|
| Status | Discontinued |
| Body | Dimensions | 140 x 71 x 9.4 mm (5.51 x 2.80 x 0.37 in) |
|---|---|---|
| Weight | 170 g (6.00 oz) | |
| SIM | Micro-SIM | |
| IP57 dust/water resistant (up to 1m. and 30 mins) |
| Display | Type | IPS LCD capacitive touchscreen, 16M colors |
|---|---|---|
| Size | 5.0 inches, 68.9 cm2 (~69.3% screen-to-body ratio) | |
| Resolution | 1080 x 1920 pixels, 16:9 ratio (~441 ppi density) | |
| Protection | Corning Gorilla Glass |
| Platform | OS | Android 4.1 (Jelly Bean) |
|---|---|---|
| Chipset | Huawei K3V2 | |
| CPU | Quad-core 1.5 GHz Cortex-A9 | |
| GPU | Vivante GC4000 |
| Memory | Card slot | No |
|---|---|---|
| Internal | 32GB 2GB RAM |
| Main Camera | Single | 13 MP, AF |
|---|---|---|
| Features | LED flash, HDR | |
| Video | 1080p@30fps |
| Selfie camera | Single | 1.3 MP |
|---|---|---|
| Video | 720p@30fps |
| Sound | Loudspeaker | Yes |
|---|---|---|
| 3.5mm jack | Yes |
| Comms | WLAN | Wi-Fi 802.11 a/b/g/n, dual-band, Wi-Fi Direct, DLNA, hotspot |
|---|---|---|
| Bluetooth | 4.0, A2DP, EDR, LE | |
| GPS | Yes, with A-GPS | |
| Radio | FM radio | |
| USB | microUSB 2.0 |
| Features | Sensors | Accelerometer, gyro, proximity, compass |
|---|
| Battery | Removable Li-Ion 3000 mAh battery |
|---|---|
| Stand-by | Up to 144 h |
| Misc | Colors | Crystal Blue, Pure White |
|---|---|---|
| Price | About 310 EUR |
Disclaimer. We can not guarantee that the information on this page is 100% correct. Read more
Huawei Ascend D2 - user opinions and reviews
- Infiniti
- fsV
Well, not too bad but can't download from google store, gets too hot on browsing and even can't update software. Pls can the makers come out openly and tell why or how to solve this problem making a good phone look bad. Or is there anyone out th..
- QAZI
- f}m
HOW you upgrade it ?
- khalid
- X}$
download mobomarket
Isliye sabhi chahte hai ki apane mobile me badhiya se badhiya ringtone ho. Diya tamil movie ringtone download 2017. Ringtone ab Craze ke sath personality status bhi ban gaya hai. The collection for top 10 ringtone of all time Popular. Best instrumental ringtones of all time, best instrumental ringtones for android Mobile, latest instrumental ringtones bollywood 2020, bollywood romantic instrumental ringtones Free Download website, world’s best 10 mobile ringtones, instrumental music ringtones free download, Top 10 RingTone 2018 hindi and English collection.sabhi Mobile – android phone use ko Ringtone pasand hota hai.
| Cell Number Specification | LBBPc | LBBPd2 | LBBPd3 | UBBPd6 | UBBPe4 | UBBPe6 | |
| 3 * 20MHz 2T2R 1 * 20M 4T4R | 3*20M 4T4R | 6*20M 2T2R | 6*20M 4T4R | 6*20M 4T4R | 12*20M 4T4R | ||
| eRAN12.1 Capacity Specification @ MBB / Smartphone Traffic Model | Bandwidth | LBBPc | LBBPd2 | LBBPd3 | UBBPd6 | UBBPe4 | UBBPe6 |
| Maximum Number of UEs in RRC_Connected Mode Per Cell | 20MHz/15MHz/10MHz | 350 | 700 | 800 | 1200 | 1200 | 1200 |
| 5MHz | 350 | 600 | 600 | 600 | 600 | 600 | |
| Maximum Number of synchronized users Per cell | 20MHz/15MHz/10MHz | 350 | 700 | 800 | 1200 | 1200 | 1200 |
| 5MHz | 200 | 600 | 600 | 600 | 600 | 600 | |
| Maximum Number of UEs in RRC_Connected Mode Per Board | 20MHz/15MHz/10MHz | 350 | 700 | 800 | 2200 | 2400 | 3600 |
| 5MHz | 350 | 700 | 800 | 2200 | 2400 | 3600 | |
| Maximum Number of synchronized users Per Board | 20MHz/15MHz/10MHz | 350 | 700 | 800 | 2200 | 2400 | 3600 |
| 5MHz | 350 | 700 | 800 | 2200 | 2400 | 3600 | |
| Maximun VoLTE User per BBP Board (with RoHC) | 20MHz | 270 | 600 | 600 | 1000 | 1200 | 1600 |
| Maximum Number of UEs in RRC_Connected Mode Per MPT Board | LMPT | 1200 | |||||
| UMPTb | 2000 | ||||||
| UMPTe | 9000 | ||||||
| Maximum Number of UEs in RRC_Connected Mode Per eNodeB | LMPT | 1200 | |||||
| UMPTb | 8000 | ||||||
| UMPTe | 9000 with 1 UMPTe 18000 with 2 UMPTe | ||||||
| Signaling Specifications (BHCA) @ MBB / Smartphone Traffic Model | LBBPc | LBBPd2 | LBBPd3 | UBBPd6 | UBBPe4 | UBBPe6 | |
| BHCA per baseband board | 63K | 126K | 144K | 396K | 432K | 648K | |
| BHCA per MPT board | LMPT | 216K | |||||
| UMPTb | 360K | ||||||
| UMPTe | 1620K | ||||||
| CA User Number Specification @ MBB / Smartphone Traffic Model | LBBPc | LBBPd2 | LBBPd3 | UBBPd6 | UBBPe4 | UBBPe6 | |
| Maximum DL 2CC CA User / PCC User Per board | 0 (Not recommend for PCC) | 350 | 400 | 1100 | 1200 | 1800 | |
| Maximum DL 3CC CA User / PCC User Per board | 0 (Not support for PCC) | 230 | 260 | 730 | 800 | 1200 | |
| Maximum DL 4CC CA user / PCC User Per board | Not Support | 175 | 200 | 550 | 600 | 900 | |
| Maximum DL 5CC CA user / PCC User Per board | Not Support | 140 | 160 | 440 | 480 | 720 | |
| Maximum UL 2CC CA User / PCC User Per board | Not Support | 350 | 400 | 1100 | 1200 | 1800 | |
| Maximum SCC User Per board | Maximum RRC connected user numbers per board - PCC user on this board | ||||||
| Maximum Non-CA User Per board | Maximum RRC connected user number per board - PCC user on this board * [1+(N-1)*0.5] - SCC user on this board*0.5 N=CC number | ||||||
